JORC | POD-TD Pneumatic zero air loss drain | 3805

The POD-TD removes condensate from compressed air systems without using electricity and without the unnecessary loss of compressed air.

The discharge process is automatic and is based on a 3/2 way level controlled valve principle that operates a piston type direct acting valve. The advantage of this valve principle is that the POD-TD’s orifice can be 6 mm, offering an increased reliability factor.

The POD-TD is ideally suited in applications where power is not available, too expensive or not reliable. The POD-TD features a specially treated robust aluminium housing suitable for oil lubricated and oil-free applications.

In addition, the POD-TD can be applied in applications that demand a higher IP rating. The POD-TD offers an IP68/NEMA6 rating.

FEATURES

• Competitive ‘true green’ solution
• No operating costs
• No electricity required - install and go!
• Operating pressure up to 230 psi
• Reduced stocking costs - 1 model covers 3,500 CFM
• Suitable for any type of compressed air system
• No complicated sizing charts required
• Compact and unique design
• Successful draining of condensate due to large orifice (also heavily emulsified condensate)
• Incredibly easy and quick to install and to service
• No complicated control air line and pressure regulator required
• Integrated strainer
• Top and side inlets available
• Test feature
• Robust aluminum housing
• Direct acting valve construction for a reliable condensate discharge operation

SPECIFICATIONS
