DESCRIPTION
Air System Products BVD-2B14, 1/4" Bronze Ball Valve Drain, 115/1/60
Non-clogging Condensate Drain for Compressed Air Systems
Designed for the toughest applications, this non-clogging, full-port ball valve drain with a solid state timer. removes condensate, (oil and water) from compressed air systems.
Features
- Solid state timer
- Straight-through flow pattern
- Robust seat and seal design
- Test button
- Available in several sizes
- NEMA 4X enclosure
- Available in different pressure ratings up to 2,000 PSI
- Versatile for many applications
Benefits
- Easy adjustability of drain cycle frequency
- Prevents clogging
- Provides extended service on the most demanding applications
- Quick check of drain operation
- Can be used on wide range of flows
- Rugged and non-corrosive
- Can be used on wide range of applications
- Can be used for filters, air receivers, air dryers, separators and aftercoolers
How it Removes Condensate from Compressed Air Systems
The BVD Drain is a non-clogging timer-based condensate drain using a full-port ball valve. A heavy-duty gear-motor housed in a NEMA 4X enclosure ensures a long service life. A solid-state timer module initiates a drain cycle by energizing the gear motor to rotate the ball valve 180° from closed to open and back to a closed position. The drain cycle lasts for approximately 8 seconds during which condensate is drained.
Specifications
| Inlet/Outlet (NPT) | 1/4″, 1/2″, 3/4″, 1″ |
| Drain Cycle Frequency | 1 min. – 50 mins. |
| Drain Cycle Time | 8 secs. |
| Pressure | Bronze – up to 600 PSI Stainless Steel – up to 2,000 PSI |
| Ground Cord | 8 ft. |
| Power | 115 V/60 HZ/1 PH |
| Weight | 6 lbs. |
| NEMA 4X Enclosure | 6″ x 3″ x 3″ |
Dimensions
| Stock No. | A | B | C | D |
| BVD-2B14 / 2S14 | 2.25″ | 6.50″ | 6.50″ | 1/4″ |
| BVD-2B12 / 2S12 | 2.25″ | 6.50″ | 7.00″ | 1/2″ |
| BVD-2B34 / 2S34 | 3.00″ | 6.75″ | 7.50″ | 3/4″ |
| BVD-2B10 / 2S10 | 3.25″ | 7.25″ | 7.75″ | 1″ |
