JORC MAG-11 drain w/ optional test button, 1/2" NPT, 0-230 PSI, Magnetically Operated Zero Air Loss Drain | 3964

JORC MAG-11 drain w/ optional test button, 1/2" NPT, 0-230 PSI, Magnetically Operated Zero Air Loss Drain | 3964

The MAG-11 is the optimum choice in compact energy saving condensate drains, typically installed in (refrigerated) dryers and under piston compressors.

Unlike timer or electronic drains, which require electricity to operate, the MAG-11 operates using a magnet level sensor providing energy saving zero air loss operation without the need for a power source.

Perfectly suited for coolers, refrigerated dryers, liquid separators and piston compressors, the MAG-11 uses a magnetically operated 2/2-way direct acting valve assembly, discharging the condensate from your compressed air system without losing any of your valuable compressed air.

The MAG-11 meets the demand of virtually any application, regardless of the condensate flow. It fits in any application, regardless of size, without any set up or adjustment.

The MAG-11 is also available with a test feature. The test button offers the solution to check your MAG-11 ensuring nothing is obstructing the orifice. It also allows you to depressurize the drain for those yearly maintenance moments.

FEATURES

• Extremely compact with top and side inlets.
• Easy to install in tight locations.
• No electricity required and no operating cost once installed.
• Level sensed magnetic technology saves air, energy and money!
• 2/2-Way direct acting valve, for a reliable discharge of virtually any condensate.
• Rugged corrosion resistant aluminium housing finished with an EP coating.
• Lightweight, yet strong and durable.
• Built in air lock prevention.
• Service kits available.
• Operating pressure 0 to 230 psi.
• Bottom (outlet) can be rotated 360° for installation simplicity.
• Also available with a test button.

SPECIFICATIONS
