The NUFORS-XF removes all types of condensate from large capacity compressed air applications up to 17500 CFM, without using electricity and without the unnecessary loss of compressed air. The NUFORS-XF has an exceptional large condensate discharge capacity of 1260 gallons condensate per hour at 230 psi.

The discharge process is automatic and is based on a 3/2 way level controlled valve principle that operates a piston type direct acting valve.

The NUFORS-XF is ideally suited in applications where power is not available, too expensive or not reliable.

In addition, the NUFORS-XF can be applied in applications that demand a higher enclosure protection rating. The NUFORS-XF offers an NEMA 6/IP68 rating.

FEATURES

• Suitable for large capacity compressed air applications up to 17500 CFM
• No electricity required - install and go
• No operating costs
• Competitive ‘true green’ solution
• Reduced stocking costs - 1 model covers 17,500 CFM
• No complicated sizing charts required
• Consult JORC for private labelling options
• Level sensing drain technology
• Incredibly easy and quick to install and to service
• No complicated control air line and pressure regulator required
• Top- and side inlets available
• TEST button feature for routine testing
• Robust corrosion resistant aluminium housing
• Direct acting valve construction for a reliable condensate discharge operation
• Successful draining of, even heavily emulsified, condensate due to a large 12 mm valve orifice

SPECIFICATIONS
