JORC MAG-11 drain, 1/2" NPT, 0-230 PSI, Magnetically Operated Zero Air Loss Drain | 3954
The MAG-11 is the optimum choice in compact energy saving condensate drains, typically installed in (refrigerated) dryers and under piston compressors.
Unlike timer or electronic drains, which require electricity to operate, the MAG-11 operates using a magnet level sensor providing energy saving zero air loss operation without the need for a power source.
Perfectly suited for coolers, refrigerated dryers, liquid separators and piston compressors, the MAG-11 uses a magnetically operated 2/2-way direct acting valve assembly, discharging the condensate from your compressed air system without losing any of your valuable compressed air.
The MAG-11 meets the demand of virtually any application, regardless of the condensate flow. It fits in any application, regardless of size, without any set up or adjustment.
The MAG-11 is also available with a test feature. The test button offers the solution to check your MAG-11 ensuring nothing is obstructing the orifice. It also allows you to depressurize the drain for those yearly maintenance moments.
FEATURES
- Extremely compact with top and side inlets.
- Easy to install in tight locations.
- No electricity required and no operating cost once installed.
- Level sensed magnetic technology saves air, energy and money!
- 2/2-Way direct acting valve, for a reliable discharge of virtually any condensate.
- Rugged corrosion resistant aluminium housing finished with an EP coating.
- Lightweight, yet strong and durable.
- Built in air lock prevention.
- Service kits available.
- Operating pressure 0 to 230 psi.
- Bottom (outlet) can be rotated 360° for installation simplicity.
- Also available with a test button.
SPECIFICATIONS
| MAXIMUM FILTER CAPACITY | Unlimited |
| MAXIMUM DRAINAGE CAPACITY | 38 gallons per hour at 230 psi (16 bar) 145 liters per hour at 230 psi (16 bar) |
| PRESSURE RANGE | 0 - 230 PSI (0 - 16 bar) |
| VALVE TYPE | 2/2 way, direct acting |
| VALVE SEALS | FPM |
| INLET CONNECTIONS | 1/2″ NPT (2*) |
| OUTLET CONNECTION | 1/8″ with hose pipe connector |
| INLET HEIGHT | 3.9" |
| MEDIUM TEMPERATURE | 34 - 122 °F |
| AMBIENT TEMPERATURE | 34 - 122 °F |
| SERVICEABLE VALVE | Yes |
| ENVIRONMENTAL PROTECTION | NEMA6 (IP68) |
| HOUSING MATERIAL | Corrosion resistant aluminium, EP coating |
| TEST FEATURE | Optionally available |
| CALIFORNIA PROPOSITION 65 | See manual |
