DESCRIPCIÓN
Features
- Straight-through flow pattern
- Robust seat and seal design
- Dual-adjustable solid-state external timer
- Pilot lights for Power (red) and Valve Open (green)
- NEMA 4X enclosure
- Multi-valve capabilities
- Self-cleaning action
- Mounting tabs for wall or panel mount
- Versatile for many applications
Benefits
- Prevents clogging
- Provides extended service on the most demanding applications
- Easy adjustment of both drain frequency and length of drain cycle
- Indicate drain status at a glance
- Rugged and non-corrosive
- PD7000 operates one to four valves at once
- Makes valve dependable in adverse conditions
- Flexible positioning
- Can be used for filters, air receivers, air dryers, separators and aftercoolers
How it Removes Condensate from Compressed Air Systems
The Posi-Drain is a premium timer drain based on the remarkable, chopping, guillotine action of the Posi Valve. This robust valve creates a non clogging, straight-through flow.
The timer initiates a drain cycle by energizing a magnet coil that slides up the seal assembly and creates a straight through flow path for condensate. When the timer times-out, the coil is de-energized and the seal assembly is spring-returned to the closed position. The opening and closing action also serves to wipe contaminants from the sealing surfaces to ensure a positive seal and no air.
Specifications
| Inlet/Outlet | 1/4″ NPT |
| Drain Cycle Frequency | 5 secs. – 50 mins. |
| Drain Cycle Time | 1 – 15 secs. |
| Pressure | 200 PSI |
| Power Cord | 8 ft. with NEMA 5-15 3-blade, 125 VAC grounded plug. |
| Voltage | 110V/1PH/60HZ. Other voltages available. Please contact factory. |
| NEMA 4X Enclosure | 6″ x 3″ x 3″ |
| Material | Body-Bronze, Seat-Stainless Steel, Seal-High Performance Thermoplastic |
Dimensions
