DESCRIPCIÓN
Features
- Dual-adjustable solid-state timer
- Pilot lights for Power (red) and Valve Open (green)
- NEMA 4X enclosure
- Mounting tabs for wall or panel mount
- Available in 1/4″ and 1/2″ sizes
- Pressure ratings up to 1500 PSI
- Vesatile for many applications
Benefits
- Easy adjustment of both drain frequency and length of drain cycle
- Indicate drain status at a glance
- Rugged and non-corrosive
- Flexible positioning
- Designed for use on a wide range of flows
- Available for use on a wide range of applications
- Can be used for filters, air receivers, air dryers, separators and aftercoolers
How it Removes Condensate from Compressed Air Systems
The Posi-Drain is a premium timer drain based on the remarkable, The solid state timer initiates a drain cycle by energizing the valve coil that opens the valve and allows the condensate to drain. When the timer times-out, the coil is de-energized and the valve is spring-returned to the closed position.
Specifications
| Inlet/Outlet | 1/4″ NPT / 1/2″ NPT |
| Drain Cycle Frequency | 5 secs. – 50 mins. |
| Drain Cycle Time | 1 – 15 secs. |
| Pressure | 200 PSI, with options for others – see chart below |
| Power Cord | 8 ft. with NEMA 5-15 3-blade, 125 VAC grounded plug. |
| Voltage | 115V/1PH/60HZ. Additional voltages available. Please contact factory. |
| NEMA 4X Enclosure | 6″ x 3″ x 3″ |
Dimensions
Ordering Information
| Stock No. | Description | Weight |
| SD11 | Sure-Drain Timer Controller with Single Valve | 2 lbs. |
| SD11-500 | 1/4″ 500 PSI | 2 lbs. |
| SD11-1500 | 1/4″ 1500 PSI | 2 lbs. |
| SD11-C12 | 1/2″ 300 PSI | 2 lbs. |
